Beats Solo 4 Wireless Headphones: How to Replace the Battery?
Have your Beats Solo 4 Wireless Bluetooth headphones refused to power on? Do they appear as fully charged when plugged into a power source, but display a red light when you try to turn them on? It might be time to replace the battery.
In this DIY at-home repair guide, we will show you how to disassemble the headphone using simple tools, replace the battery, and reassemble it, restoring the device’s functionality. You will find all the tools you need for this repair, along with the replacement battery, listed below. This will save you the trouble of buying a new pair of expensive headphones.
You can also send us your Beats Solo 4 Wireless Headphones for professional repair. Follow the link, select all the problems that apply to you, and click the See Estimated Total button for a cost estimate.
Repair Difficulty
Moderate / Requires 30-40 minutes to complete.
This repair involves the careful handling of sharp tools, fragile cables, small parts, and controlled heating. You don’t need advanced tools or technical skills to complete the repair. With a bit of patience and attention to detail, you can easily replace the battery on your Beats Solo 4 Wireless Bluetooth headphones.
Replacement Parts You’ll Need
- A Beats by Dre Solo 4 Wireless Battery Replacement (520mAh). Choose the correct part and condition from the drop-down menu below.
Tools You’ll Need
- Precision Screwdriver (Philips 2.0mm)
- Strong Metal Pry Tool
- Precision Tweezers
- Heat Gun
-
Heat-Proof Anti-Static Rubber Work Mat
If the tool cost seems prohibitive, check out our repair catalog to see if we offer repair services for your device. If you can’t find your device on the list, our repair services might be temporarily unavailable.
Step-by-Step Guide to Replacing the Battery on Your Beats Solo 4 Wireless Bluetooth Headphones
Here is a step-by-step DIY guide for replacing the battery in your Beats by Dre Solo 4 Wireless Bluetooth headphones at home. Follow the instructions carefully to avoid damaging any delicate internal components.
Step 1: Separate the Left Outer Shell Using a Pry Tool
1.1. The battery is located on the left side of your headphones: the side with the charger port. Place your Beats Solo 4 Wireless Bluetooth headphones on a heat-proof, anti-static rubber work mat. Insert a strong metal pry tool between the edges and remove the left outer shell. You will hear 4 clicks when the outer shell is ready to be separated from the headphones.
1.2. Insert the strong metal pry tool between the outer and inner shells that are still attached and use mild pressure to separate the two surfaces.
Step 2: Remove the Battery Using a Pry Tool
2.1. Using the strong metal pry tool, gently remove the battery from the housing. Be very careful not to damage the battery or any of the fragile internal cables.
2.2. Pull off the sticker attached to the rear end of the battery and discard it. You won’t need it later.
Step 3: Remove the Glue from the Battery Connector
3.1. Use a precision tweezer to remove the glue on the battery connector. Be careful not to damage the connector.
3.2. You can use a little bit of heat to soften the glue and make it pliable. Use the heat gun for no more than 5-10 seconds.
3.3. Once the glue is off, gently disconnect the old battery from the connector using precision tweezers and discard it safely.
Step 4: Install a New Battery
4.1. Grab the new battery and reconnect the cable connector.
4.2. Place the battery inside the housing, press it firmly into place, and tuck the cables along the edges of the battery.
Step 5: Reassemble Your Beats Solo 4 Wireless Bluetooth Headphones
5.1. Grab the inside panel and align it with the metal frame of the headphone so that it touches at the top end.
5.2. Grab the outside panel, align it with the inside panel and the metal frame, and press the clips on the edges back into place.
5.3. Align the outer and inner shells and squeeze them until the 4 clips click back into place.
Congratulations! Your Beats Solo 4 Wireless Bluetooth Headphones Are Ready for Use
You have successfully replaced the battery on your Beats Solo 4 Wireless Bluetooth headphones. Your device is now ready for use. Test the buttons, audio quality, and pairing to ensure the repair is successful and the headphones are working normally.
