How to Fix the Left and Right Speaker Drivers on the Beats Solo 4 Wireless Bluetooth Headphones (DIY Repair Guide)
Are your Beats Solo 4 Wireless headphones producing distorted or crackling audio, especially at higher volumes? If you’re also noticing reduced volume or complete sound loss on one side, these are strong indicators that the speaker driver may be damaged and needs to be replaced.
In this DIY repair guide, we show you how to replace the worn-out left and right speaker drivers on the Beats Solo 4 Wireless headphones at home using OEM spare parts. You will find all the tools that you need for this repair, along with genuine replacement parts, listed below.
Do you want to get your headphones professionally repaired? Send us your Beats Solo 4 Wireless headphones, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.
Video Tutorials
Here are the video tutorials for replacing the left and right speaker drivers on the Beats Solo 4. The steps are similar for both sides. We will highlight the minor differences that you need to remember while repairing the headphones yourself.
- Beats Solo 4 Wireless Left Speaker Replacement Tutorial
- Beats Solo 4 Wireless Right Speaker Replacement Tutorial
Repair Difficulty
Moderate / Requires 20-30 minutes to complete.
This repair requires the careful handling of small screws, delicate internal cables, a heat gun, and a soldering iron. Prior experience of soldering will be helpful, but is not compulsory. With the right tools, a bit of patience, and attention to detail, you can replace the blown speaker driver on the Beats Solo 4 headphones at home.
Replacement Parts You’ll Need
Restore the audio quality of your Beats Solo 4 Wireless headphones with original replacement parts. Select the OEM spares from the drop-down menu below to bring your device back to peak working condition.
- Beats By Dre Solo 4 Wireless Speaker Driver w/ Housing Replacement (Used) - Parts
Get an OEM replacement speaker driver for your Beats Solo 4 Wireless headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original replacement part and the tools you’ll need for this repair at a discount.
Tools You’ll Need
Before starting the Beats Solo 4 speaker driver replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.
- Joe’s 50-in-1 Screwdriver Set
- 1.5mm Flathead Screwdriver
- Strong Metal Pry Tool
- Precision Tweezers
- Soldering Iron
- Heat Gun
- Tacky Glue
- Heat-proof Anti-skid Rubber Work Mat
Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.
Step-by-Step DIY Guide to Replacing the Left and Right Speaker Drivers on the Beats Solo 4 Wireless Headphones
In this detailed DIY repair guide, we show you how to replace the blown speaker driver on the Beats Studio 3 Wireless headphones. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
Step 1: Remove the Earpad Cushion
Insert a sturdy metal pry tool into the seam between the earpad cushion and the earcup. Gently work the tool up and down to separate the cushion from the earcup without damaging the retaining clips.
Step 2: Separate the Speaker Housing from the Earcup
Unfasten the 3 screws holding the speaker housing to the earcup with a 2.0mm Phillips screwdriver.
Step 3: Extract the Old Speaker Driver from the Housing
3.1. Flip the speaker housing, then apply heat to soften the old adhesive over the speaker connector and remove it with a strong metal pry tool.
3.2. Desolder the speaker wires with a soldering iron. Click a photograph of the wires to use as a reference while soldering them back onto the new speaker driver.
3.3. Remove the old adhesive from the side of the speaker driver with a strong metal pry tool till it comes out.
Step 4: Install a New Speaker Driver
4.1. Solder the wires onto the new speaker driver.
4.2. Apply 8 drops of tacky glue along the perimeter of the new speaker driver to secure it in place.
Step 5: Reassemble the Beats Solo 4 Wireless Headphones
5.1. Tuck all the internal wires under the AUX port so that they don’t get in the way when you fasten the screws on the speaker housing.
5.2. Flip the speaker housing over the earcup and fasten the 3 screws with a 2.0mm screwdriver.
5.3. Align the earpad cushion with the earcup and press down till the clips click into place.
Congratulations! Your Beats Solo 4 Wireless Bluetooth Headphones are Ready to Use!
You have successfully replaced the old speaker driver on the Beats Solo 4 wireless headphones. Check audio quality, charging stability, and playback time to confirm the device is working properly.
