How to Replace the Charge Port on the Beats Studio Pro (2023) Wireless Headphones at Home (DIY Repair Guide)
Do your Beats Studio Pro Wireless (Model Number: A2924, Year: 2023) headphones experience inconsistent or unreliable charging? Do you need to wiggle the cable to get a connection, hold it at a certain angle, or notice that charging stops even with a slight movement? If you’re experiencing any of these issues, it is time to replace the charger port.
In this DIY repair guide, we show you how to replace the worn-out charger port on the Beats Studio Pro Wireless (A2924) headphones at home with original replacement parts. You will find all the tools that you need for this repair, along with the OEM spares, listed below.
Do you want to get your headphones professionally repaired? Send us your Beats Studio Pro Wireless (2023) headphones, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues that you’re experiencing, and click See Estimated Total to view the total repair cost instantly.
Repair Difficulty
Moderate / Requires 30-45 minutes to complete.
This repair requires the careful handling of small screws, delicate internal cables, and a hot soldering iron. Prior experience of soldering will be helpful, but is not compulsory. With a bit of patience and attention to detail, you can replace the charger port on the Beats Studio Pro Wireless headphones at home.
Replacement Parts You’ll Need
Restore the functionality of your Beats Studio Pro Wireless headphones with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.
- Beats Studio Pro Wireless Charger Charge Port USB-C Replacement Repair
Get an OEM replacement USB-C Charger Port for your Beats Studio Pro Wireless (2023) headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click. Explore the Beats Studio Repair Kit w/ Ear Pad Tape & Opening Tools kit for maximum savings.
Tools You’ll Need
Before starting the charger port replacement on your Beats Studio Pro Wireless (2023) headphones, gather the following tools. Using the right tools will help you complete the repair successfully, without damaging delicate internal components, such as wires, ports, or circuit boards. We used the following tools and recommend them for a safe, professional-quality DIY charger port replacement at home.
- Joe’s Cold Press Glue
- Strong Metal Pry Tool
- Precision Tweezers
- Solder Flux
- Soldering Iron
- 1.5mm Flathead Screwdriver
- 2.0mm Philips Screwdriver
- Heat-Proof Anti-Static Rubber Work Mat
Not ready to invest in tools yet? Find your device in our repair catalog, select the issues it’s experiencing, and send it to us. Our repair ninjas will restore your device to peak working condition.
Step-by-Step DIY Guide to Replacing the Charger Port on the Beats Studio Pro Wireless (2023) Headphones
In this detailed DIY repair guide, we show you how to replace the worn-out charger port on the Beats Studio Pro Wireless (2023) headphones. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
Step 1: Extract the Right Earpad Cushion
Insert the strong metal pry tool under the right earpad cushion and gently pry it off the earcup.
Step 2: Separate the Speaker Driver
2.1. Unfasten the 5 black screws using the 2.0mm Philips screwdriver. Be careful not to drop the screws in the gaps through the speaker driver.
2.2. Remove the 2 small silver screws securing the charger port and store them separately.
Step 3: Unsolder the Internal Wires
3.1. Apply solder flux on the connection points of the charger port.
3.2. Use a soldering iron to unsolder all the internal wires. Before you begin, take a clear photo of the connections. This will serve as a reliable reference when reconnecting and soldering the wires back in place.
3.3. Remove the small connector port by lifting it away from the earcup using your fingers.
Step 4: Remove the Worn-out Charger Port
Insert the flathead screwdriver or metal pry tool under the worn-out charger port. Heat the 2 connection points on the charger port with the soldering iron to melt the underlying adhesive, then gently pry away the charger port from the earcup.
Step 5: Install New USB Type-C Charger Port
5.1. Apply a thin, even layer of fresh adhesive to the base of the earcup where the new charging port will be seated.
5.2. Feed the new charger port through the slot provided on the speaker assembly.
5.3. Press down on the new charger port using your fingers until the adhesive cures.
Step 6: Solder the Internal Wires
6.1. Reconnect the speaker wires and solder each connection point securely.
6.2. Gently push the connector port in place using your fingers.
6.3. Connect the wires to the new charger port and solder them securely in place using the reference image.
6.4. Connect a USB-C cable and power source to check that the headphones charge properly and the connection remains stable.
Step 7: Assemble Your Beats Studio Pro Wireless (2023) Headphones
7.1. Reattach the speaker assembly to the earcup, ensuring the charging port is properly aligned with its slot before securing everything in place.
7.2. Fasten all 7 screws to secure the new charging port, following the correct order and orientation.
7.3. Align the earpad cushion’s indent with the charging port, then press down on both sides until the tabs click securely into place.
Congratulations! Your Beats Studio Pro Wireless (2023) Headphones are Ready to Use
You have successfully replaced the charger port on the Beats Studio Pro Wireless (2023) Bluetooth headphones. Check the charging stability, audio quality, buttons, and Bluetooth pairing to confirm the device is working properly.
