How to Replace a Malfunctioning AUX Audio Jack on the Bose QuietComfort (QC) 45 Wireless Bluetooth Headphones (DIY Repair Guide)

Do your Bose QuietComfort (QC) 45 wireless Bluetooth headphones produce no audio, crackling, or static when using a 3.5mm audio cable? Does the sound cut in and out when you touch the audio cable, or do the headphones fail to detect a wired connection? If you’re experiencing any of these issues, it’s time to replace the AUX port on the Bose QC 45 headphones.

In this DIY repair guide, we show you how to replace a malfunctioning AUX audio jack on the Bose QuietComfort (QC) 45 headphones at home with original replacement parts. Find the tools and genuine spares for this repair below.

Prefer to get your headphones repaired by professionals? Send us your Bose QuietComfort (QC) 45 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge after repairing your device.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 30-45 minutes to complete.

This repair involves carefully disassembling the Bose QuietComfort 45 headphones to reveal the faulty AUX audio jack and replacing it with genuine spare parts. You don’t need technical skills or prior experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the AUX port in the Bose QC 45 at home.

Replacement Parts You’ll Need

Restore the audio quality and playback stability of your Bose QC 45 Bluetooth headphones with genuine spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Bose QuietComfort QC35 II QC45 Audio Jack 2.5MM Port Replacement - Parts

• Bose QC25 QC35 QC45 QC SE QC Headphones Repair Tool Kit – Complete Set

Looking for another spare part? Browse Joe’s GE Parts Catalog for genuine replacement parts for your Bose QuietComfort (QC) 45 headphones.

Tools You’ll Need

Before starting the Bose QuietComfort (QC) 45 AUX audio jack 2.5mm port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• 1.5mm Phillips Screwdriver
• 1.5mm Flathead Screwdriver
• Precision Tweezers
• Soldering Iron
• Heat-Proof Anti-Static Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair. Book your repair now.

Step-by-Step DIY Guide to Replacing a Malfunctioning AUX Audio Jack (2.5mm Port) on the Bose QuietComfort (QC) 45 Headphones at Home

In this detailed DIY repair guide, we show you how to replace a loose or wobbly AUX port on the Bose QC 45 headphones yourself. The AUX port is located inside the left earcup. For this repair, we will only work on the left side. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Extract the Left Earpad Cushion

1.1. Insert one finger behind the old earpad cushion until you feel the retaining ring at its base.

1.2. Grip the ring with your fingers, then pull it upward and toward the center of the earcup to release the retaining clips and remove the cushion.

1.3. Extract the foam mesh with the pry tool and set it aside.

Step 2: Remove the Outer Earcup Housing Cover

2.1. Unfasten 2 screws holding the earcup housing cover with a 1.5mm Phillips screwdriver and set them aside.

2.2. Flip the earcup gently to dislodge the housing. If a clip is stuck, poke it with a flathead screwdriver or tweezers until the housing pops out.

2.3. Unplug the ribbon cable for the buttons from the PCB. Use a flathead screwdriver or precision tweezers to remove the adhesive patch covering the connector.

Step 3: Extract the Malfunctioning AUX Audio Port

3.1. Unfasten 2 screws holding the AUX audio jack to the earcup housing.

3.2. Peel the sticker from over the AUX connection with a flathead screwdriver and set it aside.

3.3. Insert a flathead screwdriver under the faulty AUX port to extract it from the earcup housing. Disconnect the ribbon connector on the right, then desolder the ribbon connected to the top of the board.

Pro Tip: If any connector is glued to the main board, soften the adhesive with a heat gun or soldering iron before peeling it away using precision tweezers.

Step 4: Install a New AUX Audio Jack

4.1. Grab a new AUX audio jack, align it with the earcup housing, and resolder the 3 points on the ribbon cable to the PCB.

4.2. Plug in the shorter ribbon cable with the help of precision tweezers.

4.3. Align the 2 pins on the earcup housing with the slots in the AUX port, then fasten the audio jack with 2 Phillips screws.

Step 5: Reassemble Your Bose QuietComfort (QC) 45 Headphones

5.1. Connect the ribbon cable on the outer earcup housing cover to the PCB.

5.2. Gently flip the earcup housing to align the screw holes, then fasten the 2 screws on the left side. Make sure the cover is fully flush with the speaker housing.

5.3. Align the mesh with the earcup, then press down on both ends so that the double-sided tape sticks to the earcup housing.

5.4. Grab the earpad cushion and align the clips before pushing down with your fingers. Once you hear all the retaining clips click into place, tug on all sides to confirm the earpad cushion is securely installed.

Congratulations! Your Bose QuietComfort (QC) 45 Wireless Bluetooth Headphones are Ready to Use

You have fixed the no-sound issue on the Bose QC 45 headphones by replacing the faulty 2.5mm audio jack. Check audio quality, charging stability, touch response, and Bluetooth pairing to confirm the device is working properly.
