How to Replace a Malfunctioning Gesture Touch Panel Control Pad on the Sony WH-1000XM4 (DIY Repair Tutorial)

Does the touch control panel on your Sony WH-1000XM4 headphones fail to respond or work only intermittently? Are gestures such as volume up, volume down, play/pause, or track skipping no longer working properly? These issues often indicate a faulty touch control panel. Replacing the touch control panel can restore full functionality to your headphones.

In this DIY repair guide, we show you how to replace the gesture touch control pad on the Sony XM4 wireless headphones at home with original replacement parts. You will find all the tools that you need for this repair, along with the OEM spares, listed below.

Prefer to get your headphones professionally fixed? Send us your Sony WH-1000XM4 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge you after your device has been successfully repaired.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 15-20 minutes to complete.

This repair requires careful handling of small screws, delicate internal cables, and circuit boards. You don’t need technical skills or prior experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the touch gesture panel on the Sony WH-1000XM4 wireless headphones at home.

Replacement Parts You’ll Need

Restore the touch response and user experience of your Sony XM4 wireless Bluetooth headphones with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Sony WH-1000XM4 XM4 Wireless Headphones Repair Replacement (Black) - Parts

• Sony WH-1000 XM3 XM4 XM5 XM6 Headphones Repair Screwdriver + Pry Tool Repair - Kit

Looking for another spare part? Browse the Joe’s GE Parts Catalog for the Sony WH-1000XM4 to find genuine replacement parts for your headphones.

Tools You’ll Need

Before starting the Sony WH-1000XM4 gesture touch panel replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• Joe’s 50-in-1 Screwdriver Set
• Strong Metal Pry Tool
• Precision Tweezers
• Heat-proof Anti-skid Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.

Step-by-Step DIY Guide to Replacing a Faulty Gesture Touch Control Panel on the Sony WH-1000XM4 Headphones at Home

In this detailed DIY repair guide, we show you how to replace a faulty gesture touch control panel on the Sony WH-1000XM4 headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Extract the Earpad Cushion

1.1. Insert a strong metal pry tool into the seam between the earpad cushion and the earcup, then gradually work the tool around the perimeter of the earcup till the cushion separates from the housing.

1.2. Remove the foam mesh pad and set it aside.

Step 2: Remove the Malfunctioning Gesture Touch Panel

2.1. Unfasten four 1.5mm Phillips screws from the earcup housing and set them aside.

2.2. Insert a strong metal pry tool into the seam between the gesture touch panel and the earcup, and gently work the tool till the touch pad separates.

2.3. Flip the touch pad over gently, then disconnect the ribbon cable with your fingers.

Step 3: Install New Gesture Touch Control Panel

3.1. Grab a new gesture touch control panel, then connect the ribbon cable to the main board.

3.2. Align the gesture touch pad with the earcup housing, flip it over, then fasten 4 silver screws to secure the assembly in place.

Step 4: Install the Earpad Cushion

4.1. Insert the foam mesh pad into the earcup.

4.2. Align the earpad cushion with the earcup, then press down on it till the retaining clips click securely into place.

Congratulations! Your Sony WH-1000XM4 Wireless Bluetooth Headphones are Ready to Use

You have successfully replaced the faulty gesture touch control panel on the Sony WH-1000XM4 wireless Bluetooth headphones. Check the touch control response, charging stability, audio quality, and Bluetooth pairing to confirm the device is working properly.
