How to Replace the Battery on the Sony WH-1000XM6 Headphones?

Do your Sony XM6 wireless headphones (model number: WH-1000XM6) refuse to power on or charge when connected to a power source? Do they require frequent charging or experience sudden shutdowns? If you’re experiencing any of these symptoms, it’s time to replace the battery.

In this DIY repair guide, we show you how to replace the worn-out battery on the Sony WH-1000XM6 wireless Bluetooth headphones at home with original replacement parts. You will also find all the tools that you need for this repair, along with the OEM spares listed below.

Want to get your device repaired by a professional? Send us your Sony WH-1000XM6 headphones. Follow the link, select all the issues that you’re experiencing, and click See Estimated Total to view the total repair cost instantly.

Repair Difficulty

Moderate / Requires 30-45 minutes to complete.

This repair requires careful handling of delicate internal cables, small screws, and internal components. You don’t need prior experience or technical skills. With a bit of patience and attention to detail, you can replace the battery on the Sony XM6 headphones at home.

Replacement Parts You’ll Need

Restore the battery health, listening experience, and longevity of your Sony WH-1000XM6 headphones by choosing original replacement parts. Select the OEM spares and part condition from the drop-down menus below to bring your device back to peak condition.

• OEM Sony WH-1000XM6 Replacement Battery (1050mAh, 4.35V, Model No: 633741).

Get OEM replacement batteries for your Sony WH-1000XM6 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click. Explore our Bundle and Save offer for maximum savings.

Tools You’ll Need

Before starting the battery replacement on your Sony WH-1000XM6 headphones, gather the following tools. Using the right tools will help you complete the repair without damaging any of the delicate internal components, including wires, cables, and connectors. We used the following tools and recommend them for a safe, professional-quality DIY battery replacement at home.

• Philips 1.5mm Screwdriver
• Flat Head 1.5mm Screwdriver
• Precision Tweezers
• Strong Metal Pry Tool
• Nylon Spudger

Not ready to invest in tools yet? Find your device in our Repair Catalog, select the issues it’s experiencing, and send it to us. Our repair ninjas will restore your device to peak working condition.

Step-by-Step DIY Guide to Replacing the Batteries on the Sony WH-1000XM6 Headphones at Home

In this detailed repair guide, we show you how to replace the worn-out battery on the Sony WH-1000XM6 headphones at home. Follow the instructions and refer to the corresponding images to complete the repair yourself.

Step 1: Remove the Right Earpad

1.1. The battery is located inside the right earpad. Insert a strong metal pry tool under the earpad cushion near the charging port, and gently pry it out from the rest of the earcup.

1.2. Remove the mesh piece and store it safely.

Step 2: Disconnect the Microphone from the Speaker Housing

2.1. Peel off the rubber gasket using a flathead screwdriver.

2.2. Press the side of the 2nd rubber gasket using a flathead screwdriver, and it should pop off.

2.3. Get underneath the “Y” shaped plastic tab using a flathead screwdriver and peel it off the adhesive.

2.4. Use a plastic spudger to disconnect the ribbon cable from the connector.

Step 3: Remove the Speaker Housing

3.1. Unfasten the 5 small black screws and store them safely.

3.2. Extract the plastic speaker housing using a flathead screwdriver.

3.3. As you pull the speaker housing, push the ribbon from the microphone through the opening. The ribbon is connected to the power board, and there is limited slack. Using excessive force may rip out the connector or damage the cable.

3.4. Once you create enough space, insert precision tweezers to disconnect the ribbon cable from the power board.

3.5. Disconnect the speaker wire from the power board.

Step 4: Remove the Old Battery

4.1. Unfasten the 2 small screws securing the battery case.

4.2. Unplug the battery from the power board.

4.3. Open the battery case to reveal the battery.

Step 5: Install a New Battery

5.1. Install a new 1050mAh battery and assemble the case.

5.2. Plug in the battery connector. Press down on both sides of the connector using a flathead screwdriver to secure the connection.

5.3. Place the battery case in its designated location and fasten the 2 screws.

Step 6: Attach the Speaker Housing

6.1. Connect the speaker wire to the power board. Pull the microphone cable through the opening on the speaker housing to create slack before the next step.

6.2. Connect the microphone ribbon to the power board.

6.3. Pull all the slack out from the microphone ribbon.

6.4. Fasten the 5 screws securing the speaker housing.

6.5. Connect the microphone cable to the speaker housing. Align the holes in the cable with the pins in the speaker driver, then press it down. The old adhesive is quite sticky and will hold the cable in place.

6.6. Align the 2 small holes in the “Y” shaped plastic housing with the 2 pins on the speaker driver and push down on it for a secure fit.

6.7. Tuck the ribbon cable inside the speaker housing using precision tweezers.

6.8. Install the rubber gasket.

6.9. Install the second rubber gasket. Using precision tweezers, insert the side of the gasket without the extension, then gently push the other side until it fits securely.

6.10. Install the foam mesh.

6.11. Align the earpad cushion with the earcup, find the indicator to identify which side the cushion is for, align it with the indicator on the bottom of the earcup, and press down for a secure fit.

Congratulations! Your Sony WH-1000XM6 Headphones are Ready to Use

You have successfully replaced the battery on the Sony WH-1000XM6 wireless Bluetooth headphones. Check the audio quality, buttons, and Bluetooth pairing to confirm the device is working properly.
