How to Replace a Broken or Cracked Hinge Swivel on the Sony WH-H910N (DIY Repair Tutorial)

Is the left or right hinge swivel on your Sony WH-X910N wireless Bluetooth headphones broken, wobbly, or cracked? Do the earcups feel unstable, rotate unevenly, slide out of position, or show cracks around the hinge joint? If you’re experiencing any of these issues, the hinge mechanism may be worn or damaged and due for replacement.

In this DIY repair guide, we show you how to replace the damaged left and right hinge swivel mechanism on the Sony WH-H910N wireless Bluetooth headphones using OEM spare parts. You will find all the tools needed for this repair, along with OEM replacement parts, below.

Want to get your headphones repaired by a professional? Send us your Sony WH-H910N headphones, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge you after your device has been successfully repaired.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 30-45 minutes to complete.

This repair involves handling delicate internal components, including small screws, wires, speaker housing, and circuit boards. While prior soldering experience can be handy, it’s not mandatory. With the right tools, a bit of patience, and attention to detail, you can replace the hinge swivel on the Sony WH-H910N headphones yourself.

Replacement Parts You’ll Need

Restore the form and functionality of your Sony WH-H910N wireless headphones with original replacement parts. Select the OEM spares from the drop-down menu below to bring your device back to peak working condition.

• Sony WH-H910N Hinge Swivel Replacement Left / Right BR2 BL1 Repair Part

Looking for another spare part? Browse the Joe’s GE Parts Catalog for the Sony WH-H910N to find genuine replacement parts for your headphones.

Tools You’ll Need

Before starting the Sony WH-H910N hinge swivel replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• 2.0 mm Phillips Screwdriver
• 1.5 mm Phillips Screwdriver
• Strong Metal Pry Tool
• Precision Tweezers
• Anti-static Heat-proof Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.

Step-by-Step DIY Guide to Replacing the Swivel Hinge Assembly on the Sony WH-H910N Wireless Headphones at Home

In this detailed DIY repair guide, we show you how to fix the broken, cracked, or loose hinge swivel assembly on the Sony WH-H910N headphones. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

The repair process is the same for both the left and right sides. We’ll point out any minor differences between the two sides as you work through the repair.

Step 1: Remove the Earpad Cushion

Insert a strong metal pry tool into the seam between the earpad cushion and the earcup housing, then gently work the tool around the perimeter of the earcup while pulling up the earpad until the two parts separate.

Step 2: Separate the Earcup from the Broken Hinge Swivel

2.1. Unfasten 5 Phillips screws holding the earcup together, then place them aside.

2.2. Insert a strong metal pry tool into the seam between the outer panel and the earcup housing, then gently pry upward till the panel pops off.

2.3. Unfasten 2 screws from the earcup hinge.

2.4. Unplug the gesture touch panel ribbon.

2.5. Disconnect the main wire from the PCB with precision tweezers.

2.6. Pop the earcup from one side of the hinge and press the other side till the earcup and the headband separate.

Step 3: Extract the Broken Hinge Swivel

3.1. Pull the earcup hinge swivel out from the assembly.

3.2. Remove the O-ring from the main wire.

3.3. Remove the top plastic piece from the hinge arm.

3.4. Unfasten the 4 screws from the hinge swivel.

3.5. Extract the broken hinge swivel and pull the main wire all the way through. Bend the wire near the end to push the connector out of the hinge.

Step 4: Install New Hinge Swivel

4.1. Grab the new hinge swivel and extract the small metal horseshoe lock with precision tweezers.

4.2. Pull the new hinge swivel all the way to the end of the wire. Make sure to pull the loose O-ring toward the main wire connector.

4.3. Align the new hinge swivel with the headband in the correct orientation, then lock it in place with the metal horseshoe piece.

4.4. Align the earcup hinge arm with the hinge swivel and fasten the 4 screws.

4.5. Tuck the wire into the groove on the hinge arm, then install the top plastic piece and press it securely till the retaining clips click into position.

4.6. Pull the rubber O-ring back into place.

Step 5: Reassemble the Sony WH-H910N Headphones

5.1. Align the earcup hinge swivel with the hinge arm. Make sure to align it in the correct orientation.

5.2. Align one end of the hinge swivel with the earcup, then pull the other end and fasten it with 2 screws.

5.3. Plug in the main wire connector, then tuck the wires into the groove to prevent accidentally damaging them while fastening the screws on the speaker housing.

5.4. Plug in the gesture touch panel ribbon cable.

5.5. Install the gesture touch control panel on the earcup, then flip it over and fasten the 5 screws to secure the assembly.

5.6. Align the earpad cushion with the earpad, then press them together till you hear the retaining clips click securely into place.

Congratulations! Your Sony WH-H910N Wireless Bluetooth Headphones are Ready to Use

You have successfully replaced the cracked or damaged swivel hinge assembly on the Sony WH-H910N wireless Bluetooth headphones. Check the alignment, audio quality, touch response, and Bluetooth pairing to confirm the device is working properly.
