How to Disassemble the Sony MDR-XB950N1 Wireless Headphones to Fix No Sound or Charge Issues (DIY Teardown and Repair Guide)

Do your Sony MDR-XB950N1 wireless Bluetooth headphones have a dead or failing battery? Does the charging port only work when the cable is held at a specific angle? Are the earpads or headband cracked, torn, peeling, or degrading? Does the device produce no sound, constant static, or a white hiss noise in one earcup? Does it have a floppy or broken swivel hinge? If you're experiencing any of these issues, this DIY teardown tutorial will show you how to disassemble your Sony MDR-XB950N1 headphones and complete the necessary repairs with genuine spare parts at home.

Prefer to get your earbuds professionally fixed? Send us your Sony MDR-XB950N1 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge you after your device has been successfully repaired.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 45-60 minutes to complete.

This repair involves carefully disassembling the Sony XB950N1 headphones to reveal the problematic components and replacing them with genuine spare parts. While prior soldering experience may be useful, it’s not mandatory. With a bit of patience and attention to detail, you can replace the failing components in the Sony MDR-XB950N1 wireless headphones at home.

Replacement Parts You’ll Need

Restore the form and functionality of your Sony MDR-XB950N1 wireless Bluetooth headphones with genuine spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Original Sony MDR-XB950B1 / XB950BT Replacement Repair Spare Parts

• Sony WH-1000 XM3 XM4 XM5 XM6 Headphones Repair Screwdriver + Pry Tool Repair Kit

Looking for another spare part? Browse the Joe’s GE Parts Catalog for the Sony MDR-XB950N1 to find genuine replacement parts for your headphones.

Tools You’ll Need

Before starting the Sony MDR-XB950N1 teardown, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• 1.5mm Phillips Screwdriver
• 1.5mm Flathead Screwdriver
• Nylon Spudger
• Soldering Iron
• Soldering Flux
• Heat-proof Anti-skid Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.

Step-by-Step Sony MDR-XB950N1 Teardown and Repair Guide

In this detailed DIY tutorial, we show you how to disassemble and repair the Sony MDR-XB950N1 wireless Bluetooth headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Remove the Earpad Cushions

1.1. Grip the earpad cushion with your fingers and gently pull it away from the earcup to release it from the retaining clips.

1.2. Insert a flathead screwdriver into the seam between the mesh pad and the earcup housing, then gently work the tool around the perimeter to remove the mesh pad.

Repeat the steps on both earcups.

Step 2: Disassemble the Left Earcup

2.1. Unfasten the 4 Phillips screws securing the speaker housing to the earcup.

2.2. Lift the speaker housing gently to reveal the wires. Apply soldering flux to the connection, then desolder the speaker wires.

2.3. Peel away the adhesive tape to reveal the solder points on the main board.

2.4. Take a photo of the wires to use as reference during reassembly, then apply soldering flux to all the connections.

2.5. Desolder all the wires connected to the main board.

2.6. Unfasten 3 small black screws from the main board with a 1.5mm Phillips screwdriver.

2.7. Gently wiggle the main board out from the housing with your fingers, then set it aside.

2.8. Remove the LED light indicators and the MS port.

2.9. Pop the earcup hinge from the swivel assembly with your fingers, then pull the main wire out from the other side.

Step 3: Disassemble the Left Headband Hinge Swivel Assembly

3.1. Remove the plastic piece from the hinge arm with a flathead screwdriver.

3.2. Insert a flathead screwdriver into the seam between the two halves of the swivel arm, then gently work the tool around the perimeter till the two parts separate.

3.3. Pull the main wire out from the swivel arm.

3.4. Unfasten 2 screws securing the swivel assembly with a 1.5mm Phillips screwdriver.

3.5. Remove the metal horseshoe lock with a flathead screwdriver, then pull the main wire out from the swivel arm.

3.6. Unfasten the 2 Phillips screws from the headband swivel hinge.

3.7. Pull out the small tab marked "L" to expose the screw. Use a 1.5 mm Phillips screwdriver to remove the single screw securing the slider mechanism, then remove the outer panel.

3.8. Unfasten the 2 Phillips screws holding the hinge assembly, then pull the main wire out from the hinge.

3.9. Pop off the inside panel.

Step 4: Disassemble the Right Earcup

4.1. Unfasten the 4 screws attached to the speaker housing and flip it. Be careful not to tear the wire.

4.2. Disconnect the battery.

4.3. Spread the wires with your fingers, then take a picture of the connection to use as a reference while reassembling the headphones.

4.4. Apply soldering flux to the connections, then desolder all the wires from the power board.

4.5. Remove the 2 screws from the power board with a 1.5mm Phillips screwdriver, then remove the board from the earcup housing and set it aside.

4.6. Pull the mic-side (MS) port out of the earcup housing.

4.7. Pull the earcup swivel away from the headband.

4.8. Remove the battery from the earcup housing with a nylon spudger.

Step 5: Disassemble the Right Headband Hinge Swivel Assembly

5.1. Remove the top plastic piece of the earcup swivel with a flathead screwdriver.

5.2. Insert a flathead screwdriver into the seam between the inner and outer panels of the swivel arm.

5.3. Pull the main wire out from the right swivel arm.

5.4. Unfasten the two 1.5mm Phillips screws from the swivel arm.

5.5. Remove the metal horseshoe lock with a flathead screwdriver, then slide the main wire out from the swivel arm.

5.6. Unfasten the 2 screws from the headband swivel assembly with a 1.5mm Phillips screwdriver.

5.7. Pull out the small tab marked "R" to expose the screw. Use a 1.5 mm Phillips screwdriver to remove the single screw securing the slider mechanism, then remove the outer panel.

5.8. Remove the 2 screws from the swivel hinge with a 1.5mm Phillips screwdriver, then slide it out from the main wire.

5.9. Pop the inner panel away from the headband slider.

Congratulations! Your Sony MDR-XB950N1 Wireless Bluetooth Headphones Teardown Is Complete

You have completely disassembled your Sony MDR-XB950N1 headphones down to their individual components. Replace any damaged or malfunctioning parts with genuine OEM spares from our store, then reverse your steps to reassemble the headphones and restore them to full working condition.
