How to Replace a Dead or Dying Battery on the Sony WF-1000XM4 Charging Case (DIY Repair Guide)
Has the battery life of your Sony WF-1000XM4 earbuds dropped significantly? Does the charging case fail to charge the earbuds properly, or do they never reach 100% even after sitting in the case for several hours? These are common signs of a failing charging case battery. Replacing the battery can restore reliable charging and extend the overall performance of your earbuds.
In this DIY repair guide, we show you how to fix a dead or dying battery in the Sony Wf-1000XM4 in-ear earbuds using new OEM spares without technical skills or experience. You will find all the tools required for this repair and original replacement parts below.
Prefer to get your earbuds professionally repaired? Send us your Sony WF-1000XM4 earbuds using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.
Repair Difficulty
Easy / Requires 10-15 minutes to complete.
This repair requires carefully disassembling the charging case without damaging delicate internal components such as wires, battery, and circuit boards. You don’t need technical skills or prior experience to complete this repair. With a bit of patience and attention to detail, you can replace the battery on the Sony WF-1000XM4 charging case at home.
Replacement Parts You’ll Need
Restore the functionality of your Sony WF-1000XM4 earbuds with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.
- Sony WF-1000XM4 Charger Case Replacement Battery 520mAh 3.85V (YY2948)
Get an OEM replacement battery for your Sony WF-1000XM4 in-ear earbuds today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click.
Tools You’ll Need
Before starting the Sony WH-1000XM5 Bluetooth board replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.
Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.
Step-by-Step DIY Guide to Replacing a Dead or Dying Battery on the Sony WF-1000XM4 In-Ear Earbuds Yourself
In this detailed DIY repair guide, we show you how to fix a dead or dying battery on the Sony WF-1000XM4 in-ear earbuds yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
Step 1: Disassemble the Charging Case
1.1. Insert a plastic spudger into the seam between the outer cover and the charging case while firmly squeezing the top and bottom with your thumb and middle finger. Carefully release the four retaining clips securing the cover, then lift it off. Store the outer cover in a safe place until reassembly.
1.2. Unclip the 2 connectors on the charging case with a nylon spudger.
1.3. Pull the battery housing away from the charging case with your fingers.
Step 2: Extract the Dead or Dying Battery from the Charging Case
2.1. Unplug the battery cable from the PCB with a nylon spudger.
2.2. Pull the battery cover off the battery with your fingers and set it aside.
2.3. Use a nylon spudger to carefully pry the battery away from the housing and remove it. The battery is secured with double-sided adhesive tape, so try to preserve the tape as you separate the battery. Discard the old battery after removal.
Step 3: Install a New Battery
3.1. Align the new battery with the housing and press firmly till the double-sided tape forms a strong bond.
3.2. Align the battery cover and press down till you hear it clip into place.
3.3. Connect the battery cable with the PCB.
Step 4: Reassemble the Sony XM4 Earbud Charging Case
4.1. Tuck the cables neatly into the charging case, then align the four retaining clips on the front and rear of the battery housing. Press the two halves together until all four clips snap securely into place.
4.2. Align the outer cover with the charging case then press down till you hear the clips click into place.
Congratulations! Your Sony WF-1000XM4 Charging Case Battery Replacement is Complete
You have successfully replaced the battery on the Sony WF-1000XM4 in-ear earbud charging case. Test the charging function to ensure the earbuds charge properly and confirm that the case closes securely with no gaps or misalignment.
