How to Replace a Dead or Dying Battery on the Sony WH-1000XM3 Wireless Bluetooth Headphones (DIY Repair Tutorial)
Do your Sony WH-1000XM3 wireless headphones refuse to power on, require frequent recharging, shut down unexpectedly even when the battery hasn’t dropped to 1%, deliver significantly shorter playback time, or fail to charge when connected to a power source? These are all common signs of a worn-out battery. Replacing the battery can restore reliable performance and bring your headphones back to their original battery life.
In this DIY repair guide, we show you how to replace a dead or failing battery on the Sony WH-1000XM3 wireless Bluetooth headphones at home with original replacement parts. You will find all the tools that you need for this repair, along with OEM spares below.
Prefer to get your headphones professionally fixed? Send us your Sony WH-1000XM3 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. Select your device and the issue you're experiencing, then click Continue. Enter your email address and click Get My Estimate to receive an instant repair estimate.
Repair Difficulty
Moderate / Requires 30-45 minutes to complete.
This repair involves carefully handling delicate internal components, including ribbon cables, connectors, battery, and small screws. You don’t need technical skills or experience to complete this repair. With a bit of patience and attention to detail, you can replace the battery on the Sony WH-1000XM3 headphones yourself.
Replacement Parts You’ll Need
Restore the functionality of your Sony XM3 headphones with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.
- Sony WH-1000XM3 XM3 Wireless Headphones Repair Replacement (Black) - Parts
Get an OEM replacement battery for your Sony WH-1000XM3 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click.
Tools You’ll Need
Before starting the Sony WH-1000XM3 battery replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.
Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.
Step-by-Step DIY Guide to Replacing a Dead or Failing Battery on the Sony WH-1000XM3 Wireless Bluetooth Headphones Yourself
In this detailed DIY repair guide, we show you how to fix a worn-out battery on the Sony WH-1000XM3 headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
Step 1: Remove the Right Earpad
The battery is located in the right earcup. So, we’ll only need to work on the right side.
1.1. Insert a strong metal pry tool into the seam between the earpad and the earcup and gently work the tool along the perimeter till the earpad cushion separates.
1.2. Set the foam pad aside.
Step 2: Remove the Touch Panel
2.1. Use a 1.5 mm Phillips screwdriver to remove the four screws securing the touch panel, then store them separately. The two upper screws are longer than the two lower screws, so make sure to reinstall each screw in its original position during reassembly.
2.2. Flip the headphones over, then insert a strong metal pry tool between the touch panel and the earcup housing and separate the two components.
2.3. Unplug the touch panel ribbon cable from the power board, then set it aside.
Step 3: Extract the Worn-out Battery
3.1. With a strong metal pry tool, gently lift the black tape with the ribbon attached to it from the battery and move it out of the way. Be careful not to break the cable or rip it from the power board.
3.2. Unplug the battery from the power board with a strong metal pry tool.
3.3. Move the wires out of the way.
3.4. Insert a sturdy metal pry tool underneath the battery and carefully work it around the edges to loosen the adhesive. Continue prying gently until you can lift the battery out of the housing.
Step 4: Install a New Genuine Battery
4.1. Align a new OEM 1000mAh battery with the housing, then gently press down on it with your fingers till the adhesive bonds with the surface.
4.2. Tuck the wires back under the clip.
4.3. Connect the battery cable to the power board.
4.4. Place the black tape over the battery.
Step 5: Reassemble the Sony XM3 Headphones
5.1. Reattach the touch panel ribbon cable to the power board.
5.2. Flip the touch panel over and secure it with four 1.5mm screws.
5.3. Align the foam pad with the earcup housing and place it in the correct orientation.
5.4. Align the tabs on the earpad cushion with the grooves on the earcup housing and press them together till you hear the retaining clips click into place.
Congratulations! Your Sony WH-1000XM3 Wireless Bluetooth Headphones are Ready to Use!
You’ve successfully replaced the battery on your Sony WH-1000XM3 headphones. Check the charging stability, battery life, touch response, and audio quality to confirm the device has been repaired professionally.
