How to Replace a Loose or Wobbly Charger Port on the Sony WH-1000XM5 Headphones (DIY Repair Tutorial)
Do your Sony WH-1000XM5 Wireless headphones experience inconsistent or unreliable charging? Do you need to wiggle the cable to get a connection, hold it at a certain angle, or notice that charging stops even with a slight movement? If you’re experiencing any of these issues, it is time to replace the charger port.
In this DIY repair guide, we show you how to replace the worn-out charger port on the Sony XM5 wireless headphones at home with original replacement parts. You will find all the tools that you need for this repair, along with the OEM spares, listed below.
Prefer to get your earbuds professionally fixed? Send us your Sony WH-1000XM5 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.
Repair Difficulty
Moderate / Requires 30-45 minutes to complete.
This repair requires the careful handling of small screws, delicate internal cables, and connection ports. You don’t need technical skills or prior experience to complete this repair. With a bit of patience and attention to detail, you can replace the charger port on the Sony WH-1000XM5 wireless headphones at home.
Replacement Parts You’ll Need
Restore the functionality of your Sony XM5 wireless Bluetooth headphones with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.
- Sony WH-1000XM5 XM5 Wireless Headphones Repair Replacement - Parts
- Sony WH-1000 XM3 XM4 XM5 XM6 Headphones Repair Screwdriver + Pry Tool Repair - Kit
Get an OEM replacement charger port for your Sony WH-1000XM5 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click.
Tools You’ll Need
Before starting the Sony WH-1000XM5 charging port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.
- 1.5mm Phillips Screwdriver
- 1.5mm Flathead Screwdriver
- Plastic Spudger
- Strong Metal Pry Tool
- Heat-Proof Anti-Static Rubber Work Mat
Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.
Step-by-Step DIY Guide to Replacing a Wobbly or Loose Charging Port on the Sony WH-1000XM5 Headphones at Home
In this detailed DIY repair guide, we show you how to replace a loose or wobbly charger port on the Sony WH-1000XM5 headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
Step 1: Remove the Right Earpad Cushion
The charging port is located inside the right earcup. We will start the repair process by disassembling the right earcup.
1.1. Insert a strong metal pry tool into the seam between the earpad cushion and the earcup, then gently work the tool along the perimeter till the two halves separate.
1.2. Remove the foam pad and set it aside.
Step 2: Separate the Touch Panel and the Earcup Housing
2.1. Unfasten the 8 2.0mm Phillips screws from the earcup housing and store them in one of the slots provided on the rubber work mat.
2.2. Flip the touch panel, disconnect the ribbon cable, and set it aside.
Step 3: Disconnect the Battery
Disconnect the battery wires with a flathead screwdriver.
Step 4: Extract the Wobbly or Loose Charging Port from the Housing
4.1. Disconnect the charging port, MS port, and microphone ribbon cables.
4.2. Unplug the main internal wire from the circuit board.
4.3. Unfasten the 2 small screws to remove the power board.
4.4. Preserve the thermal paste by pasting it on the power board.
4.5. Lift the waterproof gasket halfway to access the charging port.
4.6. Unfasten the single screw securing the charging port to the earcup housing.
4.7. Pull the ribbon cable out from the top piece.
4.8. Place the waterproof gasket back on the top piece.
4.9. Unfasten the single screw securing the worn-out charging port to the housing.
4.10. Discard the old charging port.
Step 5: Install New Charging Port
5.1. Install a new charging port and secure it in place with a single screw.
5.2. Feed the charging port ribbon cable through the gasket in the top piece.
5.3. Fasten the single screw on the top piece.
Step 6: Reassemble the Sony WH-1000XM5
6.1. Reinstall the waterproof rubber gasket by pressing down with your fingers.
6.2. Install the power board and fasten it with 2 screws.
6.3. Reconnect the charging port, microphone, MS port, main board, and battery ribbon cables.
6.4. Reconnect the touch panel ribbon cable.
6.5. Align the touch panel with the earcup, then flip it over and fasten all 8 screws with a 1.5mm Phillips screwdriver.
6.6. Insert the foam mesh.
6.7. Align the earpad cushion with the earcup and press them together till the clips click into place.
Congratulations! Your Sony WH-1000XM5 Wireless Bluetooth Headphones are Ready to Use
You have successfully replaced the loose or wobbly charging port on the Sony WH-1000XM5 headphones. Check the charging stability, audio quality, touch response, and Bluetooth pairing to confirm the device is working properly.
