How to Replace a Malfunctioning Bluetooth Board on the Sony WH-1000XM5 Wireless Bluetooth Headphone (DIY Repair Guide)

Do your Sony WH-1000XM5 wireless headphones fail to pair with your smartphone or tablet, suffer from weak or constantly dropping Bluetooth connections, or lose wireless functionality altogether? If you’re experiencing any of these issues, replacing the Bluetooth board may restore stable wireless connectivity and normal operation.

In this DIY repair guide, we show you how to fix a bad Bluetooth board in the Sony WH-1000XM5 wireless headphones using new OEM spares without technical skills or experience. You will find all the tools required for this repair and original replacement parts below.

Prefer to get your headphones professionally fixed? Send us your Sony WH-1000XM5 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.

Repair Difficulty

Moderate / Requires 30-45 minutes to complete.

This repair requires the careful handling of small screws, delicate internal cables, and connection ports. You don’t need technical skills or prior experience to complete this repair. With a bit of patience and attention to detail, you can replace the Bluetooth board on the Sony WH-1000XM5 wireless headphones at home.

Replacement Parts You’ll Need

Restore the functionality of your Sony XM5 wireless Bluetooth headphones with original spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Sony WH-1000XM5 XM5 Wireless Headphones Repair Replacement - Parts

• Sony WH-1000 XM3 XM4 XM5 XM6 Headphones Repair Screwdriver + Pry Tool Repair – Kit

Get an OEM replacement Bluetooth board for your Sony WH-1000XM5 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click.

Tools You’ll Need

Before starting the Sony WH-1000XM5 Bluetooth board replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• 1.5mm Phillips Screwdriver
• 1.5mm Flathead Screwdriver
• Strong Metal Pry Tool
• Soldering Iron
• Heat-Proof Anti-Static Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.

Step-by-Step DIY Guide to Replacing the Malfunctioning Bluetooth Board on the Sony WH-1000XM5 Wireless Bluetooth Headphones Yourself

In this detailed DIY repair guide, we show you how to fix a faulty Bluetooth board on the Sony XM5 wireless headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Remove the Left Earpad Cushion

The Bluetooth board is located inside the left earcup. We will start the repair process by disassembling the left earcup.

1.1. Insert a strong metal pry tool into the seam between the earpad cushion and the earcup, then gently work the tool along the perimeter till the two halves separate.

1.2. Remove the foam pad and set it aside.

Step 2: Disassemble the Left Earcup

2.1. Unfasten 8 small silver screws securing the speaker driver and the earcup housing.

2.2. Remove the back panel and set it aside.

2.3. Disconnect all the internal cables from the circuit board.

2.4. Desolder the 2 wires.

2.5. Unfasten the 3 screws from the Bluetooth board with a 1.5mm Phillips screwdriver.

2.6. Remove the old Bluetooth board and discard it.

Step 3: Install New Bluetooth Board

3.1. Align the 2 pins on the new Bluetooth board with the grooves on the earcup housing, then secure it in place with three 1.5mm Phillips screws.

3.2. Reconnect all the internal ribbon cables with the Bluetooth board.

3.3. Solder the 2 wires back on the new Bluetooth board. The copper wire goes on the left side and the red goes on the right.

Step 4: Reassemble the Sony WH-1000XM5 Headphones

4.1. Place the back panel over the earcup, flip it over, and fasten the 8 screws.

4.2. Install the foam mesh.

4.3. Align the earpad cushion with the earcup, then press down till you hear the clips click into place.

Congratulations! Your Sony WH-1000XM5 Wireless Bluetooth Headphones are Ready to Use!

You have successfully replaced the malfunctioning Bluetooth board on the Sony XM5 wireless headphones. Check Bluetooth connectivity, audio quality, and playback time to confirm the device is working properly.
