How to Replace the Left and Right Speaker Drivers on the Sony XM6 Wireless Bluetooth Headphones to Fix No Sound (DIY Repair Guide)
Are your Sony WH-1000XM6 wireless Bluetooth headphones producing distorted or crackling audio, especially at higher volumes? If you’re also noticing reduced volume or complete sound loss on one side, these are strong indicators that the speaker driver may be damaged and needs to be replaced.
In this DIY Sony XM6 no sound repair guide, we will show you how to replace worn-out left and right speaker drivers with new OEM spare parts at home. You will find all the tools required for this repair, along with the original replacement parts, below.
Prefer to get your earbuds professionally repaired? Send us your Sony WH-1000XM6 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.
Repair Difficulty
Moderate / Requires 30-45 minutes to complete.
This repair requires carefully handling small screws, delicate internal ribbon cables, and connectors. You don’t need technical skills or experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the blown speaker drivers on your Sony XM6 headphones at home.
Replacement Parts You’ll Need
Restore the audio quality of your Sony WH-1000XM6 wireless Bluetooth headphones with original replacement parts. Select the OEM spares from the drop-down menu below to bring your device back to peak working condition.
- OEM Sony WH-1000XM6 XM6 Replacement Repair Spare Parts
- Sony WH-1000 XM3 XM4 XM5 XM6 Headphones Repair Screwdriver + Pry Tool Repair – Kit
Get an OEM replacement speaker driver for your Sony WH-1000XM6 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original spare part and the tools you’ll need for this repair, all in one click.
Tools You’ll Need
Before starting the Sony WH-1000XM6 speaker driver replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.
- 1.5mm Phillips Screwdriver
- 1.5mm Flathead Screwdriver
- Strong Metal Pry Tool
- Precision Tweezers
- Heat-proof Anti-skid Rubber Work Mat
Don’t want to DIY? Let our certified techs handle the repair for you. Book your repair now.
Step-by-Step DIY Guide to Replacing the Left and Right Speaker Drivers on the Sony WH-1000XM6 Wireless Bluetooth Headphones
In this detailed DIY repair guide, we show you how to replace the blown left and right speaker drivers on the Sony XM6 wireless headphones. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.
We’re starting the repair from the right side. If you want to replace only the left speaker driver, navigate to the left speaker driver replacement section.
Step 1: Remove the Right Earpad Cushion
1.1. Insert a strong metal pry tool into the seam between the right earpad cushion and the earcup housing, then gently work the tool around the perimeter till the two parts separate.
1.2. Remove the right foam pad and set it aside.
Step 2: Extract the Right Speaker Driver
2.1. Unfasten the 5 small Phillips screws and store them safely in one of the slots provided on the rubber work mat.
2.2. Dislodge the rubber tab with a flathead screwdriver, then pull it out with your fingers.
2.3. Unplug the microphone ribbon from the main board with precision tweezers.
2.4. Unplug the main speaker wire from the PCB with a flathead screwdriver.
Step 3: Install a New Right Speaker Driver
3.1. Plug the speaker wires back into the power board.
3.2. Fasten the five 1.5mm Phillips screws onto the speaker housing.
3.3. Install the microphone ribbon to the main board cable with precision tweezers and a flathead screwdriver.
3.4 Tuck the wires and components down with your fingers, then reinstall the rubber tab over the ribbon connector.
Step 4: Install the Right Earpad Cushion
4.1. Insert the right foam pad into the groove.
4.2. Align the tabs on the right earpad cushion with the divots on the right earcup, and press along the perimeter till you hear the retaining clips click into place.
Step 5: Remove the Left Earpad Cushion
5.1. Insert a strong metal pry tool into the seam between the left earpad cushion and the earcup housing, then gently work the tool around the perimeter till the two parts separate.
5.2. Remove the left foam pad and set it aside.
Step 6: Extract the Blown Left Speaker Driver
6.1. Unfasten the five 1.5mm Phillips screws from the speaker housing, then store them separately in one of the slots on the work mat.
6.2. Remove the rubber tab with a flathead screwdriver.
6.3. Unplug the microphone ribbon cable from the main board.
6.4. Unplug the main speaker wire from the Bluetooth board with a flathead screwdriver.
Step 7: Install a New Left Speaker Driver
7.1. Connect the main speaker wire to the Bluetooth board.
7.2. Reinstall the five screws on the speaker housing with a 1.5mm Phillips screwdriver.
7.3. Connect the left mic-side (MS) ribbon cable to the Bluetooth board.
7.4. Install the left rubber pad.
Step 8: Install the Left Earpad Cushion
8.1. Insert the right foam pad into the groove.
8.2. Align the tabs on the left earpad cushion with the divots on the earcup, and press along the perimeter till you hear the retaining clips click into place.
Congratulations! Your Sony WH-1000XM6 Wireless Bluetooth Headphones are Ready to Use
You have successfully replaced the blown left and right speaker drivers on your Sony WH-1000XM6 Bluetooth wireless headphones. Check the audio quality, charging stability, and playback time to confirm the device is working properly.
