Apple AirPods Max [A2096] - How to Replace the Battery
Have you noticed a significant decrease in battery life or unexpected shutdowns while using your Apple AirPod Max headphones? If so, it may be time to replace the battery to restore optimal performance and enjoy your listening experience once again.
Replacing the battery on your Apple AirPod Max headphones is a moderately challenging task that requires careful handling and attention to detail, but with the right tools and guidance, it can be accomplished successfully.
Parts you'll need 🧰
- A replacement battery (Pick the right part for your AirPods Max from the drop-down Below)
- Click here and scroll down to view the part, with all the tools you'll need in the "Frequently bought together" section
If the tool cost seems prohibitive, check out our repair catalog to see if we offer repair services for your device. If it's not listed, we don't repair it.
_____________________________________________
Steps to Repair your AirPods Max Headphone
If the repair process is daunting, check out our repair catalog to see if we offer repair services for your device. If it's not listed, we don't repair it.
Step 1: Remove the Speaker Housing Screws
1.1 Pop the right ear pad off.
1.2 Using the screwdriver with the P5 bit, remove the screws from the speaker housing by turning them about a quarter of the way (clockwise for screws 1 and 3, counterclockwise for screws 2 and 4). Ensure you do not completely remove the screws; just loosen them.
\
Step 2: Pry Off the Speaker Housing
2.1 Use your pry tool to carefully work it into the side of the speaker housing.
2.2 Gently pry up the housing until it comes off.
2.3 Remove the housing.
Step 3: Remove the Speaker
3.1 Switch to the T3 bit and remove the screws holding the speaker in place. Be cautious of the magnetized speaker; ensure screws do not fall into it. Note that the top screws are different sizes than the bottom screws.
3.2 Remove the speaker.
Step 4: Remove the Shield Cover
4.1 Use the T3 bit to remove the first screw holding the shield.
4.2 Switch to the T2 bit for the second screw.
4.3 Carefully pop the shield out and set it aside.
Step 5: Remove Additional Screws
5.1 Remove the screws holding down the battery and power board using the T3 bit.
5.2 For the last two screws, switch back to the P5 bit.
Step 6: Disconnect the Battery
6.1 Use your flathead screwdriver to gently pop the battery ribbon off the power board.
6.2 Pull the battery out carefully and set it aside.
Step 7: Install the New Battery
Note: If your battery does not have the shell/housing around it, follow this guide.
7.1 Take the new battery and place it back into its position.
7.2 Use the P5 bit to install the two screws you previously removed from the inside.
Step 8: Reassemble the Components
8.1 Switch back to the T3 bit and reinstall the three screws for the speaker. Ensure the long screw goes at the bottom and the shorter screws at the top.
8.2 Reconnect the battery ribbon to the power board by lining it up and pressing down.
Step 9: Replace the Shield Cover
9.1 Pop the shield cover back into place.
9.2 Install the long screw on the top and the short screw on the bottom.
Step 10: Reinstall the Speaker
10.1 Place the speaker back in, ensuring the pins make contact with the connection points.
10.2 Reinstall the speaker screws.
Step 11: Finalize Assembly
11.1 Place the speaker housing back on and tighten all four screws with a quarter turn using the P5 bit.
11.2 Finally, reattach the ear cup to complete the assembly.
Step 12. Get back to enjoying your gear 🤓
You have successfully replaced the battery on your Apple AirPod Max headphones. If you have any questions or need further assistance, feel free to reach out!
