How to Replace the Charging Port on the 2018-2020 Apple iPad Pro 12.9-Inch 3rd and 4th Gen (DIY Repair Guide)

Does your Apple iPad Pro (2018-2020, 3rd and 4th Gen, Model Numbers: A1876, A1895, A1983, A2014, A2069, A2229, A2232, and A2233) experience inconsistent or intermittent charging? Do you have to hold the cable at an odd angle or wiggle it to get a connection? Does the device stop charging with the slightest movement? If you experience any of these symptoms, it’s time to replace the charger port on the 2018-2020 Apple iPad Pro 12.9-inch 3rd and 4th Gen.

In this DIY repair guide, we show you how to replace the worn-out charger port on the Apple iPad Pro with OEM spare parts. You will find all the tools needed for this repair, along with OEM replacement parts, below.

Want to get your device repaired by a professional? Send us your 2018-2020 Apple iPad Pro 12.9-inch (3rd and 4th Gen), and our repair ninjas will restore your device to peak working condition.  Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.

Repair Difficulty

Moderate / Requires 40-50 minutes to complete.

This repair involves carefully removing the fragile display from the iPad housing without cracking it and preserving the delicate internal cables and antennas during disassembly. You don’t need prior experience or technical skills to complete this repair yourself. With the right tools, patience, and attention to detail, you can replace the charging port on the 2018-2020 Apple iPad Pro 12.9-inch yourself.

Replacement Parts You’ll Need

Restore your Apple iPad Pro’s charging functionality with original replacement parts. Select the OEM spares from the drop-down menu below and bring your device back to peak working condition.

• Apple iPad Pro 11" (1st, 2nd) and (3rd, 4th Gen) 12.9" USB-C Charger Port 2018-2020 - Parts

• Apple iPad Repair Kit Pro Air Screen Opening Resealing Tool Set

Get an OEM replacement charging port for your 2018-2020 Apple iPad Pro (3rd and 4th Gen) 12.9-inch today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original replacement part and the tools you’ll need for this repair at a discount.

Tools You’ll Need

Before starting the 2018-2020 Apple iPad Pro 12.9-inch (3rd and 4th Gen) charging port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY repair at home.

• 2.0mm Phillips Screwdriver
• 1.5mm Flathead Screwdriver
• Nylon Spudger
• Heat Gun
• Apple iPad LCD Screen Removal Thin Pry Star Shape Tool
• Apple iPad LCD Tablet Screen Removal Thin Triangle Shape Plastic Pry Pick Tool
• 3M Double-sided Tape (2mm)
• 3M Double-sided Tape (4mm)
• Heat-proof Anti-skid Rubber Work Mat

Not ready to invest in tools yet? Find your device in our repair catalog, select the issues it’s experiencing, and send it to us. Our repair ninjas will restore your device to peak working condition.

Step-by-Step DIY Guide to Replacing the Old Charging Port on the 2018-2020 Apple iPad Pro (3rd and 4th Gen) 12.9-Inch at Home

In this detailed DIY repair guide, we show you how to replace the old wobbly charging port on the 2018-2020 Apple iPad Pro 12.9-inch yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Extract the Display

Place the iPad Pro with the display up and the volume buttons on the bottom left.

1.1. Heat the screen over the volume control with a heat gun set to 200°C (392°F). Once the adhesive has softened, insert a thin flexible star pry tool into the seam between the display and the housing to separate them.

Pro Tip: Pry the display with a gentle up-and-down motion while moving the heat gun along the edge of the screen. Avoid concentrating heat on a single area, as excessive heat can damage the internal cables and connectors or deform the housing.

1.2. Once the screen starts to lift, insert a plastic pick tool into the gap to prevent the adhesive from resealing as you continue to separate the display from the housing.

1.3. Insert a second pick tool and work your way along the seam on all 4 sides. Do not push the pick deep into the seam, or you may tear the display ribbon cable.  Apply heat as necessary to soften the adhesive.

1.4. Stand the iPad Pro up and apply heat along the seam while gently lifting the pick to separate the display from the housing.

1.5. Use your fingers to widen the gap as you work your way around all 4 sides.

1.6. With the display up and the front cameras at the bottom, gently lift the screen toward the charging port to reveal the Face ID connector. Unfasten the 2 screws to remove the top plate, then disconnect the ribbon cable from the main board.

Step 2: Remove the Old Charging Port

2.1. Flip the display over carefully without tearing the ribbon cable. Unfasten the 5 screws over the top plate to reveal the charging port. The single screw at the top of the picture is slightly longer than the others. Store them separately to avoid mix-up during reassembly.

Optional Step: You may disconnect the display ribbon cable and detach the screen completely to create additional working space.

2.2. Unfasten the 2 small screws over the charging port with a 2.0mm Phillips screwdriver.

2.3. Disconnect the ribbon cable with a nylon spudger and peel the tape. Once the old charging port comes off, discard it. Clean the area thoroughly with isopropyl alcohol to remove any old gunk that may have accumulated over time.

Step 3: Install New Charging Port

3.1. Align the new charging port with the housing, connect the ribbon cable, and fasten the 2 screws to secure the assembly in place.

3.2. Scrape away old adhesive tape from the housing and the display with a flathead screwdriver.

3.3. Apply 4mm double-sided tape on the right and bottom sides where the charging port is located. Use the thinner 2mm tape on the top and left sides, where the bezel is slightly thinner.

3.4. Cut the excess tape on all 4 corners with a paper cutter.

Repair Ninja Tip: Locate the two divots along the edge of the housing where the display magnet is seated. Cut small slits in the adhesive tape above and below each divot to allow the magnet to sit flush against the housing and prevent tension from building up in the tape as you install the display.

Step 4: Reattach the Display

4.1. Connect the display ribbon to the main board. Place it over the top and press with your fingers till you feel it clip in.

4.2. Install the top plate over the connectors and fasten all 5 screws. Remember that the single screw at the bottom is longer than the rest of the screws.

4.3. Flip the display over the housing, connect the Face ID ribbon, insert the top plate, and fasten the 2 screws to secure the assembly.

4.4. Align the display with the housing and run your fingers on all sides to ensure both parts sit flush, ensuring a waterproof seal.

Congratulations! Your 2018-2020 Apple iPad Pro 12.9-inch (3rd and 4th Gen) is Ready to Use!

You have successfully replaced the worn-out charger port on the 2018-2020 Apple iPad Pro (3rd and 4th Gen). Check the charging stability and touch response to confirm that the device is working properly.
