How to Replace the Beats Solo 4 Main Wire and 5-Core Wire to Fix the No Sound Issue (DIY Repair Guide)

Does your Beats Solo 4 produce no sound in one ear, or does the audio cut in and out when you adjust the headband slider? Over time, repeated folding, stretching, and everyday use can cause the main wire running through the headband to fray, break, or develop intermittent connections. Common symptoms include crackling sounds, audio dropouts, or sound that temporarily returns when the headphones are moved into a certain position.  If you’re experiencing any of these symptoms, it may be time to replace the main wire.

In this DIY repair guide, we show you how to replace the damaged main wire on the Beats Solo 4 wireless Bluetooth headphones using OEM spare parts. We will also replace the 5-core wire while the headphones are open, since it is a common failure point on Beats Solo 3 and Solo 4 models. You will find all the tools needed for this repair, along with OEM replacement parts, below.

Want to get your headphones repaired by a professional? Send us your Beats Solo 4 headphones today, and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, click Continue, enter your email ID, and click Get My Estimate to view the repair cost instantly.

Repair Difficulty

Difficult / Requires 60-75 minutes to complete.

This repair involves the full teardown of the Beats Solo 4 wireless Bluetooth headphones. You must carefully disassemble the device without tearing delicate internal ribbon cables, damaging various connection ports, connectors, and circuit boards, or rupturing the battery. Prior experience of tearing down headphones will be helpful, although with a bit of patience and attention to detail, even first-timers can complete this repair at home.

Replacement Parts You’ll Need

Restore the audio quality of your Beats Solo 4 headphones with original replacement parts. Select the OEM spares from the drop-down menu below and bring your device back to peak working condition.

  • Beats Solo 4 Wireless A3140 Main Wire + 5-Core Internal Wire Repair Kit w/ Tools



  • Genuine Beats Solo 4 Wireless Main Internal Wire Assembly (A3140) – Parts



  • Beats By Dre Solo 2 Solo 3 Solo 4 Wireless 5 Core Wire with Clip - Parts



  • Beats By Dre Solo 4 Wireless Headband Arch Replacement (New) - Parts



  • Beats By Dre Solo 4 Wireless Headband Cushion Replacement – Parts



  • Beats By Dre Solo 2 Solo 3 & Solo 4 Wired Wireless 3M Die Cut Ear Pad Cushion Adhesive - Tape



Get an OEM replacement main wire for your Beats Solo 4 headphones today. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original replacement part and the tools you’ll need for this repair at a discount.

Tools You’ll Need

Before starting the Beats Solo 4 main wire and 5-Core wire replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully, without damaging delicate internal components, including cables, circuit boards, and connector ports. We used the following tools and recommend them for a safe, professional-quality DIY main and 5-core wire replacement on the Beats Solo 4 at home.

Not ready to invest in tools yet? Find your device in our repair catalog, select the issues it’s experiencing, and send it to us. Our repair ninjas will restore your device to peak working condition.

Step-by-Step Guide to Replacing the Main Wire and 5-Core Wire on the Beats Solo 4 Wireless Bluetooth Headphones at Home

In this detailed DIY repair guide, we show you how to replace the main and the 5-core wires on the Beats Solo 4 wireless Bluetooth headphones at home. Follow the instructions and refer to the corresponding images to restore your device’s form and functionality.

Step 1: Disassemble and Separate the Left Earcup from the Headphones

1.1. Insert a strong metal pry tool into the seam between the earcup and the earpad cushion and gently pry upward to remove it.

Insert pry tool between under earpad cushion to remove it

1.2. Peel away the old adhesive tape from the underside of the earpad cushion.

Peel off the old adhesive tape

1.3. Unfasten the 3 small screws securing the speaker housing using a 2.0mm Phillips screwdriver.

Unfasten the 3 screws from the speaker driver

1.4. Pull the speaker housing off the earcup.

Pull the speaker driver off the earcup

1.5. Apply heat using a heat gun or hair dryer to soften the adhesive over the connection point where the main wire is attached to the speaker housing.

Apply heat to soften the adhesive over the points where the main wire is soldered to the speaker driver

1.6. Peel away the old adhesive using a flathead screwdriver.

Peel away the old adhesive

1.7. Desolder all the wires connected to the main cable, leaving the two internal wires untouched. Apply solder flux to each connection point to help ensure the wires are removed cleanly and efficiently. Click a photograph of the wire connections to use as a reference during reassembly.

Unsolder the wires connected to the main cable

1.8. Insert a strong metal pry tool into the seam between the outer plastic cover and the earcup. Gently work the tool up and down to separate the two pieces. Be careful not to damage the clips on the inside or outside panels.

Remove the outer plastic panel

1.9. Pull the main wire through the hole in the earcup. Remove the excess glue as necessary.

Pull the wire through the earcup

1.10. Unplug the main wires from the circuit board using precision tweezers.

Unplug the main wires from the circuit board

1.11. Unfasten the single screw from the circuit board.

Unfasten the single screw from the circuit board

1.12. Pull the main wire away from the earcup.

Pull the old main wire off the earcup

Step 2: Replace the Old Left 5-Core Cable with New Genuine OEM Spares

2.1. Disconnect the old 5-core cable connection using precision tweezers and discard the old wire.

Remove the old 5 Core Cable

2.2. Plug in the new 5-Core cable.

Plug in the new 5-core cable

Step 3: Disassemble and Separate the Right Earcup from the Headphones

3.1. Unfasten the 3 small screws securing the speaker housing to the right earcup.

Extract the 3 small screws from the speaker driver

3.2. Flip the speaker housing and pull the main wire off the adhesive.

Remove the main wire

3.3. Using a heat gun or hair dryer, apply heat to soften the glue covering the connection points. Remove the old adhesive using tweezers.

Apply heat to soften the adhesive over the points where the main wire is soldered to the speaker driver

3.4. Desolder the wire connected to the circuit board. Click a photograph for visual reference during reassembly.

Desolder the wires connected to the main board

3.5. Using a pair of tweezers or a flathead screwdriver, remove the excess adhesive on the earcup so that you can pull the main wire through it.

Remove the excess adhesive to make way for wire extraction

3.6. Flip the earcup, then insert a strong metal pry tool under the outer shell of the earcup and separate the two halves just like Step 1.8.

Separate the outer cover on the right earcup

3.7. Extract the charger port wire and the main wire using precision tweezers through the hole in the earcup.

Extract the charger port wire

3.8. Insert a strong metal pry tool under the battery and very gently pry it away from the adhesive tape.

Extract the battery

3.9. Disconnect the main wire using precision tweezers. You can soften the adhesive over the connection with some heat from a heat gun.

Disconnect the main wire

3.10. Pull the main wire away from the right earcup.

Pull the main wire out from the earcup

Step 4: Disassemble the Headband

4.1. Insert a strong metal pry tool at the edge where the headband meets the slider mechanism and pry the leather slightly to reveal the 2 small screws on both sides of the headband.

Reveal the 2 screws under the headband cushion

4.2. Unfasten the 2 small screws on both sides of the headband using the 2.0mm Phillips screwdriver.

Unfasten the 2 small 2.0mm screws

Ninja Insight: When reassembling the Beats Solo 4 headphones, remember that the number 4 is etched on the right slider hinge, while the left hinge has no markings.

4 on right slider hinge

4.3. Pull the 2 tiny pins off the slider hinge using precision tweezers for better access while inserting the new main wire. You may need to apply some heat so that the pins come out easily. Repeat this process on both sides.

Pull the pins off the hinge

4.4. Since you will be replacing the main wire, cut it using a blade for easier extraction.

Cut the main wire for easier extraction

Professional Tip: The headband slightly tilts inward toward the front, which is only visible from the top. It’s important that you identify the left and right sides during reassembly to ensure proper fitment after the repair.

Check the left and right sides of the headphone from above

4.5. Insert a strong metal pry tool between the two halves of the headband cushion and gently pry the two sides off the headband arch.

Separate the two halves of the headband cushion

4.6. Pull the old wire off the headband arch and discard it.

Pull the old wire off the headband arch

Step 5: Insert the New Main Wire into the Headband Assembly

5.1. The main wire has 2 clips on the left side and 1 on the right. Align both ends correctly to avoid having to start all over again.

Left side has 2 clips and right side has 1

5.2. Feed the new main wire through the left and right slider hinges. Make sure you insert the wire in the correct orientation.

Feed the main wire through the slider hinge

5.3. Insert the small pin into the hinge using precision tweezers. Make sure the in goes into the side that it came out of. Repeat the process with both hinges.

Insert pin into hinge

5.4. Align each end of the headband arch with the slider hinges and push them into place.

Align the headband arch with the slider hinges and push them into place

5.5. Pull on the centre of the main wire to ensure that it sticks out equally on both ends.

Make sure both sides of the main wire are even

5.6. Push the main wire into the groove provided on the headband arch.

Push the main wire into the groove on the headband arch

5.7. Align the ends of the headband cushion with the headband arch and push the two halves together.

Align the ends of the headband cushion with the headband arch and push them into place

Keep in Mind: There are 2 small notches at both ends of the headband cushion. You can align them with the pegs on the headband arch or tear the notches using precision tweezers for an easy fit. The assembly is held together with screws. Removing these small notches does not affect the structural integrity of the headphones.

Align notches on the headband cushion with pegs on the headband arch

5.8. If you notice a small gap where the earpad cushion meets the slider hinge, pop the metal piece and slide it back down over the ends of the cushion for a flush fit.

Push earpad cushion below slider hinge

5.9. Fasten 2 screws at the end of the slider hinge. Repeat the process on the other side.

Fasten the 2 screws on the slider hinge

Step 6: Reassemble the Left Earcup

6.1. Reattach the main wire to the power board using precision tweezers.

Reattach the main wire to the circuit board

6.2. Fix the main wire into the slot provided in the slider hinge using super glue and let it cure for 5 minutes. Repeat the process on both sides.

Fix the main wire using super glue

6.3. Make sure the main wire is tight where the earcup slider is fully extended.

Align the wire with the earcup slider

6.4. Push the wires into the slots provided on the earcup using precision tweezers and fix them in place using super glue.

Push the wires into the grooves
Fix the main wire using super glue

6.5. Force a flathead screwdriver into the hole through which the main wire will pass and ream the edges to widen the gap.

Widen the hole on the speaker housing for the wire to pass

6.6. Feed the wires through the widened hole.

Feed the wires through the widened hole

6.7. Align the outer and inner panels and press them together till you hear the clips click into place.

Fuse the outer and inner panels

6.8. Test the sliding mechanism by extending the earcup all the way and retracting it to ensure it’s moving freely.

Test the sliding mechanism

6.9. Solder the wires back onto the speaker housing according to the reference photograph from Step 1.7.

Solder the wires back on

6.10. Push the wires into the earcup as you align the speaker housing with the earcup, then fasten the 3 screws to secure the two pieces together.

Fasten the 3 screws on the speaker housing

Pro Tip: Make sure none of the wires are visible in the screw hole before you start fastening the 3 screws. If not, you may end up tearing through the wires.

Step 7: Reassemble the Right Earcup

7.1. Apply super glue to the groove in the hinge slider where the main wire will sit.

Apply super glue to the groove on the hinge slider where the main wire will sit

7.2. Press the main wire into the hinge slider and wait 5 minutes for the adhesive to cure.

Press the wire into the hinge slider

7.3. Connect the internal wires using precision tweezers.

Connect the internal wires

7.4. Widen the gap in the speaker housing using a flathead screwdriver for the wires to pass unobstructed.

Widen the gap using a screwdriver

7.5. Feed the black charger port wire through the hole first since it’s the widest, followed by the red and blue wires.

Fit 3 wires through the hole

7.6. Align the ends of the wire to make sure it is tight when the hinge slider is extended. Secure all the wires to the earcup by placing the battery over them and pushing the adhesive tape into place.

Cover the wires with the battery

7.7. Combine the outer and inner panels and press on the edges till you hear the clips click into place. Test the hinge slider to ensure it is working properly.

Combine the outer and inner panels

7.8. Solder the wires back on according to the reference photograph from Step 3.4.

Solder the wires according to the reference image

7.9. Combine the speaker housing and the earcup. Fold the wires so that they don’t get in the way.

Combine the speaker housing and the earcup

7.10. Make sure the wires are not visible under the screw holes, then fasten the 3 screws.

Fasten the 3 screws on the earcup

Step 8: Attach the Earpad Cushions

8.1. Peel the old tape from the earpad cushions.

Peel the old earpad cushion tape

8.2. Install new earpad cushion tape.

Install new earpad cushion tape

8.3. Align the earpad cushions with the correct earcups and press them together for 10 seconds or till the adhesive cures.

Place the earpad cushions back on the earcups

Congratulations! Your Beats Solo 4 Wireless Bluetooth Headphones are Ready to Use

You have successfully replaced the main wire on the Beats Solo 4 wireless Bluetooth headphones. Check the charging stability, audio quality, buttons, and Bluetooth pairing to confirm the device is working properly.

Beats Solo 4 Main Wire Replacement Complete
