How to Replace the Battery on the Beats Studio 3 Wireless Headphones at Home (DIY Repair Guide)

Do your Beats Studio 3 Wireless headphones refuse to power on, require frequent charging, or shut down unexpectedly? If playback time has noticeably decreased or the device shows a full charge but drains quickly, these are clear signs the battery may need replacement.

In this DIY repair guide, we show you how to disassemble the Beats Studio 3 Wireless headphones, replace the battery with a new OEM spare part, and reassemble them yourself without technical skill or experience. You will find all the tools required for this repair and original replacement parts below.

Want to get your headphones repaired by a professional? Send us your Beats Studio 3 Wireless headphones and our repair ninjas will restore your device to peak working condition. Follow the link, select the issues you’re experiencing, and click See Estimated Total to view the repair cost instantly.

Repair Difficulty

Moderate / Requires 30-45 minutes to complete.

This repair requires the careful handling of delicate internal components, such as plastic parts, wires, and circuit boards. You don’t need technical skills or prior experience to replace the battery on the Beats Studio 3 Wireless headphones. With a bit of patience and attention to detail, you can complete this repair yourself.

Replacement Parts You’ll Need

Restore the functionality of your Beats Studio 3 Wireless headphones by using original replacement parts. Select the OEM spares from the drop-down menus below to bring your device back to peak working condition.

• Beats By Dre Studio Pro Wireless Battery Replacement 640mAh Repair + Tools - Kit

• Beats By Dre Solo Pro Studio 2 3 Wired Wireless Battery Upgrade (New)

Get a new upgraded 640mAh replacement battery for your Beats Studio 3 Wireless headphones to experience longer playback and better battery life. Click the link to visit our store, then scroll down to the Customers Also Add section to purchase the original replacement part and the tools you’ll need for this repair at a discount. Explore the Beats Studio Repair Kit w/ Ear Pad Tape & Opening Tools kit to buy the parts and tools with one click.

Tools You’ll Need

Before starting the repair, it’s essential to gather all the tools. This will help you successfully replace the battery on the Beats Studio 3 Wireless headphones without damaging the delicate internal components. We used the following tools and recommend them for a safe, professional-quality DIY battery replacement at home.

• 1.5mm Flathead Screwdriver
• 2.0mm Philips Screwdriver
• Strong Metal Pry Tool
• Soldering Iron
• Heat-Proof Anti-Static Rubber Work Mat

Not ready to invest in tools yet? Find your device in our repair catalog, select the issues it’s experiencing, and send it to us. Our repair ninjas will restore your device to peak working condition.

Step-by-Step DIY Guide to Replacing the Battery on the Beats Studio 3 Wireless Headphones at Home

In this detailed DIY repair guide, we show you how to replace the battery on the Beats Studio 3 Wireless headphones at home. Follow the instructions and refer to the corresponding images to restore your device’s battery life.

Step 1: Pry Out the Outer Ring on the Right Earcup

The battery is located in the right earcup. Insert the flathead screwdriver into the indent on the plastic outer ring and pry it out. Apply gentle pressure as the ring is glued onto the earcup.

Step 2: Remove the Back Panel

2.1. Extract the 4 screws using the Philips 2.0mm screwdriver.

2.2. Remove the plastic tab by inserting the flathead screwdriver into the edge and prying upward.

2.3. Insert the strong metal pry tool in the gap between the earcup and the outer plastic cover and pry swiftly while pushing inward in one single motion. Always move quickly to avoid damaging the clips on the outer panel.

Step 3: Extract the Worn-out Battery

3.1. Insert the strong metal pry tool under the battery and pry up to extract it from the earcup.

3.2. Disconnect the wires from the 2 connection points using a heat source to soften the adhesive. We used a soldering iron. You can also use a heat gun or hairdryer. Apply moderate heat uniformly to soften the glue without damaging the circuit board or the connector ports.

3.3. Extract the power board from the earcup by inserting the flathead screwdriver under the power board and gently prying upward.

3.4. Use a flathead screwdriver to pop out the battery wire from under the power board, extract the worn-out battery, and discard it.

Step 4: Install New OEM Battery

4.1. Connect the battery wire to the power board.

4.2. Press the power board back onto the earcup till you hear the clips click into place. Make sure no cables get pinched between the board and the plastic housing.

4.3. Peel off the sticker at the back of the new battery to reveal the adhesive.

4.4. Press the battery into place for the adhesive to work.

Step 5: Assemble the Beats Studio 3 Wireless Headphones

5.1. Adjust the clip on the slider mechanism to ensure the earcups hold their position when you adjust the headband to your convenience.

5.2. Test the headphones by powering them on and pressing the buttons to make sure the new battery is installed correctly.

5.3. Align the slider hinge with the plastic panel. Make sure the slider is at the topmost point.

5.4. Align the grooves on the earcup with the points on the plastic panel and press both sides together. Test the slider mechanism and make sure no wires are in the way of the screw holes.

5.5. Fasten the 4 screws. Extend the slider all the way out to ensure that no internal wires get in the way.

5.6. Align the clip on the outer ring with the indent on the earcup and press the ring into place.

5.7. Install the plastic tab by pressing the clips into place.

Congratulations! Your Beats Studio 3 Wireless Headphones are Ready to Use!

You have successfully replaced the battery on the Beats Studio 3 Wireless Bluetooth headphones. Check the charging stability, audio quality, buttons, and Bluetooth pairing to confirm the device is working properly.
