How to Fix the No-Charge Issue on the Bose QuietComfort (QC) 35 (I and II) by Replacing a Loose or Wobbly Charging Port (DIY Repair Guide)

Do your Bose QuietComfort (QC) 35 (1st and 2nd Generations) wireless Bluetooth headphones charge inconsistently? Do you have to wiggle the charging cable or hold it at a certain angle to get a stable connection? If you experience any of these issues, the charging port may be worn out and needs to be replaced.

In this DIY repair guide, we show you how to replace a loose or wobbly charging port on the Bose QuietComfort (QC) 35 wireless headphones at home with original replacement parts. Find the tools and genuine spares for this repair below.

Prefer to get your headphones repaired by professionals? Send us your Bose QuietComfort (QC) 35 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge after repairing your device.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 20-25 minutes to complete.

This repair involves carefully disassembling the Bose QuietComfort 35 headphones to reveal the faulty charging port and replacing it with genuine spare parts. You don’t need technical skills or prior experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the charger port in the Bose QC 35 headphones at home.

Replacement Parts You’ll Need

Restore the charging functionality of your Bose QC 35 (I and II) Bluetooth headphones with genuine spares. Select OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Bose QuietComfort QC35 I QC35 II Charger Port Replacement - Parts

• Bose QC25 QC35 QC45 QC SE QC Headphones Repair Tool Kit – Complete Set

Looking for another spare part? Browse Joe’s GE Parts Catalog for genuine replacement parts for your Bose QuietComfort (QC) 35 headphones.

Tools You’ll Need

Before starting the Bose QuietComfort (QC) 35 charging port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• Joe's 50-in-1 Precision Screwdriver Set
• 1.5mm Phillips Screwdriver
• Precision Tweezers
• Nylon Spudger
• T8000 Adhesive
• Heat-Proof Anti-Static Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair. Book your repair now.

Step-by-Step DIY Guide to Replacing a Wobbly or Loose Charging Port on the Bose QuietComfort (QC) 35 Headphones at Home

In this detailed DIY repair guide, we show you how to replace a loose or wobbly charging port on your Bose QC 35 headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Remove the Right Earpad Cushion

The charging port on the Bose QuietComfort (QC) 35 is on the right side. We will only work on the right earcup for this repair.

1.1. Grab the earpad cushion with your fingers, then pull it off the retaining clips.

1.2. Remove the mesh from the earcup and set it aside. It is secured with double-sided tape, so peel it away gently to preserve the adhesive for reinstallation.

Step 2: Extract the Outer Earcup Housing

2.1. Unfasten the three 1.5mm screws holding the outer earcup housing.

2.2. Flip the earcup, then insert a nylon spudger into the seam between the outer cover and earcup housing and pry till the two parts separate. Set the cover aside for reassembly.

Step 3: Extract the Worn-out Charging Port

3.1. Unplug the ribbon cable from the charging port with precision tweezers.

3.2. Unfasten the two 1.5mm Phillips screws securing the charging port to the earcup housing.

3.3. Pry the old charging port out of the earcup housing using precision tweezers.

3.4. Disconnect the small ribbon cable connected to the charging port.

Step 5: Install a New Charging Port

5.1. Grab a new charging port, then reconnect the small ribbon cable with the help of precision tweezers.

5.2. Place the new charging port into the earcup housing, then secure it with 2 Phillips screws.

5.3. Reconnect the other ribbon cable to the new charging port.

5.4. Apply 3 dots of T8000 adhesive over the ribbon connector and wait for it to cure.

Step 6: Reassemble Your Bose QuietComfort (QC) 35 Headphones

6.1. Place the outer earcup housing cover over the earcup housing, grab it with both hands and flip it, then fasten 3 Phillips screws to secure it to the earcup housing.

6.2. Reinstall the mesh pad over the earcup housing with double-sided adhesive tape.

6.3. Grab the earpad cushion, align the lip with the slot in the earcup housing, then push the retaining clips into place.

Congratulations! Your Bose QuietComfort (QC) 35 (I and II) Wireless Bluetooth Headphones are Ready to Use

You have fixed the no-charge issue on the Bose QC 35 (1st and 2nd Generations) Bluetooth headphones by replacing the loose or wobbly charging port. Check charging stability, audio quality, button response, and Bluetooth pairing to confirm the device is functioning properly.
