How to Fix the No-Charge Issue on the Bose QuietComfort (QC) 45 Bluetooth Headphones by Replacing a Loose or Wobbly Charging Port (DIY Repair Guide)

Do your Bose QuietComfort (QC) 45 wireless Bluetooth headphones charge inconsistently? Do you have to wiggle the charging cable or hold it at a certain angle to get a stable connection? If you experience any of these issues, the charging port needs to be replaced.

In this DIY repair guide, we show you how to replace a loose or wobbly charging port on the Bose QuietComfort (QC) 45 wireless headphones at home with original replacement parts. Find the tools and genuine spares for this repair below.

Prefer to get your headphones repaired by professionals? Send us your Bose QuietComfort (QC) 45 headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge after repairing your device.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 20-25 minutes to complete.

This repair involves carefully disassembling the Bose QuietComfort 45 headphones to reveal the faulty charger or AUX PCB and replacing it with genuine spare parts. You don’t need technical skills or prior experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the charging port in the Bose QC 45 headphones at home.

Replacement Parts You’ll Need

Restore the charging functionality of your Bose QC 45 Bluetooth headphones with genuine spares. Select OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Bose QuietComfort / QC45 / SE Charger Port PCB USB-C Type-C 867287-0010 / 0020 – Parts

• Bose QC25 QC35 QC45 QC SE QC Headphones Repair Tool Kit – Complete Set

Looking for another spare part? Browse Joe’s GE Parts Catalog for the Bose QuietComfort (QC) 45 headphones to find genuine replacement parts.

Tools You’ll Need

Before starting the Bose QuietComfort (QC) 45 charging port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• 2.0mm Phillips Screwdriver
• 1.5mm Flathead Screwdriver
• Precision Tweezers
• Heat-Proof Anti-Static Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair. Book your repair now.

Step-by-Step DIY Guide to Replacing a Wobbly or Loose Charging Port on the Bose QuietComfort (QC) 45 Headphones at Home

In this detailed DIY repair guide, we show you how to replace a loose or wobbly charging port on your Bose QC 45 headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Remove the Right Earpad Cushion

The charging port on the Bose QuietComfort (QC) 45 is on the right side. We will only work on the right earcup for this repair.

1.1. Grab the earpad cushion with your fingers, then pull it off the retaining clips.

1.2. Carefully remove the mesh from the earcup and set it aside. It is secured with double-sided tape, so peel it away gently to preserve the adhesive for reinstallation.

Step 2: Extract the Outer Earcup Housing

2.1. Unfasten the three 2.0mm screws holding the outer earcup housing.

2.2. Flip the earcup and shake it gently until the outer housing falls out.

2.3. Disconnect the ribbon cable connecting the earcup housing to the main board. You may have to peel off the tape covering the connector in your headphones.

Step 3: Extract the Loose or Wobbly Charging Port

3.1. Unfasten 2 screws holding the charging port to the earcup housing with a 2.0mm Phillips screwdriver, then set them aside.

3.2. Unplug the 2 ribbon cables connected to the charging port.

3.3. Pull the old charging port out of the earcup housing and discard it.

Step 4: Install a New Charging Port

4.1. Grab a new charging port and plug in the smaller ribbon cable with precision tweezers.

4.2. Fasten 2 screws to secure the charging port to the earcup housing. Make sure the charging port lines up with the opening on the earcup housing.

4.3. Reconnect the bigger ribbon cable using precision tweezers.

Step 5: Reassemble the Bose QuietComfort (QC) 45 Headphones

5.1. Plug in the ribbon cable from the outer cover to the main board.

5.2. Flip the outer housing cover with the earcup and align it with the power button. Make sure the outer cover sits flush with the earcup housing.

5.3. Secure the earcup housing cover by fastening three 2.0mm Phillips screws.

5.4. Reinstall the mesh in the earcup housing with double-sided tape.

5.5. Grab the earpad cushion, align the lip with the slot in the earcup housing, then push the retaining clips into place.

Congratulations! Your Bose QuietComfort (QC) 45 Wireless Bluetooth Headphones are Ready to Use

You have fixed the no-charge issue on the Bose QC 45 Bluetooth headphones by replacing the loose or wobbly charging port. Check charging stability, audio quality, button response, and Bluetooth pairing to confirm the device is functioning properly.
