How to Replace a Malfunctioning Charger or AUX Port on the Bose QuietComfort (QC) Ultra (DIY Repair Tutorial)

Do your Bose QuietComfort (QC) Ultra wireless Bluetooth headphones experience inconsistent charging? Do you have to wiggle the charging or AUX cable or hold it at a certain angle to get a stable connection? If you experience any of these issues, the AUX or charger PCB may be due for replacement.

In this DIY repair guide, we show you how to replace a loose or wobbly charger or AUX port on the Bose QuietComfort (QC) Ultra wireless headphones at home with original replacement parts. Below you will find all the tools that you need for this repair, along with the OEM spares.

Prefer to get your headphones professionally repaired? Send us your Bose QuietComfort (QC) Ultra headphones using our mail-in repair service, and our repair ninjas will restore your device to peak working condition. You don’t need to pay upfront. We only charge after repairing your device.

Fill out our repair form to receive your free prepaid shipping label, then send your device. We’ll take care of the rest.

Repair Difficulty

Moderate / Requires 20-25 minutes to complete.

This repair involves carefully disassembling the Bose QuietComfort Ultra headphones to reveal the faulty charger or AUX PCB and replacing it with genuine spare parts. You don’t need technical skills or prior experience to complete this repair. With the right tools, a bit of patience, and attention to detail, you can replace the charging or AUX port in the Bose QC Ultra headphones at home.

Replacement Parts You’ll Need

Restore the charging functionality of your Bose QC Ultra Bluetooth headphones with genuine spares. Select the OEM replacement parts from the drop-down menu below to bring your device back to peak working condition.

• Bose QuietComfort Ultra Headphones Charger Port PCB USB-C + AUX Port Repair - Parts

Looking for another spare part? Browse Joe’s GE Parts Catalog for the Bose QuietComfort (QC) Ultra to find genuine replacement parts for your headphones.

Tools You’ll Need

Before starting the Bose QuietComfort (QC) Ultra charging port replacement, gather the following tools. Using the correct instruments will help you complete the repair successfully. We used the following tools and recommend them for a safe, professional-quality DIY fix at home.

• Philips 1.5mm Screwdriver
• Precision Tweezers
• Strong Metal Pry Tool
• Heat-Proof Anti-Static Rubber Work Mat

Don’t want to DIY? Let our certified techs handle the repair. Book your repair now.

Step-by-Step DIY Guide to Replacing a Wobbly or Loose Charging or AUX Port on the Bose QuietComfort (QC) Ultra Headphones at Home

In this detailed DIY repair guide, we show you how to replace a loose or wobbly charger port on the Bose QC Ultra headphones yourself. Follow each step carefully and use the accompanying images as a visual guide to complete the repair with confidence.

Step 1: Extract the Earpad Cushion

The charging or AUX port on the QC Ultra is in the left earcup. So, for this repair, we will only work on the left side.

1.1. Insert a strong metal pry tool into the seam between the earpad cushion and the earcup, and gently pry it off.

1.2. Extract the foam mesh with the pry tool and set it aside.

Step 2: Extract the Speaker Housing

2.1. Unfasten 4 screws securing the speaker housing with the earcup and store them in one of the slots on the rubber work mat.

2.2. Gently flip the speaker housing from the bottom to reveal the speaker cable. Use precision tweezers to flip the lock and unplug the ribbon cable, then set the speaker aside.

Step 3: Extract the Malfunctioning Charging or AUX Board

3.1. Unfasten 2 screws securing the charging board to the earcup housing with a 1.5mm Phillips screwdriver.

3.2. Peel back the tape to separate the small LED indicator light from the earcup housing.

3.3. Lift the charging board to reveal the ribbon cable, then disconnect it with precision tweezers.

Repair Ninja Tip: You may need to gently peel the adhesive cover away from the ribbon cable using precision tweezers before you can disconnect it.

3.4. Pull the tape with the LED indicator away from the old charging board. You need to install the light on the new board.

Step 4: Install a New Charging or AUX Board

4.1. Grab a new AUX or charging board and install the LED indicator over the LED light on the board, then secure it with the black tape.

4.2. Reconnect the ribbon cable for the charging board.

4.3. Align the new charging or AUX board with the earcup housing. Make sure the LED indicator light lines up with the small hole in the housing.

4.4. Secure the charging board to the earcup housing with two 1.5mm Phillips screws.

Step 5: Reassemble Your Bose QuietComfort Ultra Headphones

5.1. Reconnect the ribbon cable from the speaker housing to the main board.

5.2. Flip the speaker housing over the earcup, then secure the assembly by fastening four 1.5mm Phillips screws.

5.3. Insert the foam mesh.

5.4. Align the grooves on the earpad cushion with those on the earcup and push them into place.

Congratulations! Your Bose QuietComfort (QC) Ultra Wireless Bluetooth Headphones are Ready to Use

You have fixed the no charge issue on the Bose QC Ultra headphones by replacing the loose or wobbly charging or AUX port. Check the charging stability, audio quality, touch response, and Bluetooth pairing to confirm the device is working properly.
